Description
LED Battery Indicator 48V – Round
- 100% Brand New & High Quality
- Easy to Follow Pictured Instructions Included
- Colored LED Indicator Status
- Color: Black
- Water Resistant
- 10 LED Bar Display
- Operating Voltage: 48 Volt
Battery Indicator Levels Explained:
The battery indicator has 10 colored LED’s that will display the batteries voltage charge. Only 1 LED will be illuminated at a time to conserve the power draw. When your batteries are fully charged, the far right LED will illuminate green. As the batteries voltage drops from use, the LEDS in the 4 thru 9 position will illuminate. All of the 9th-4th LED’s are Green as shown the the flashing graphic above. Once the batteries voltage drops significantly the battery indicator switches to a Yellow LED cautioning there is approximately 30% of the batteries voltage left, This should be your warning for low voltage. When the batteries voltage is discharged to around 20% remaining, the 2nd LED from the left will illuminate as a flashing Yellow LED. Finally, when the battery voltage drops to 10% or less, the 1st and 2nd LED will start to flash Red and Yellow LED.
Dimensions:
Hole cutout needed on dash – 2″
Manufacturer: Automotive Authority
