Airmar B60 Bronze Thru-Hull Transducer — 20° Beam, Humminbird 9-Pin (Model B60-20-HB)

Description

B60 Bronze Thru-Hull Transducer w/Humminbird #9 Plug – 7-Pin – 20º

The bronze B60-20º provides a vertical beam without a fairing. Inside the housing, the ceramic element is tilted for built-in, deadrise compensation. The resulting vertical beam gives excellent echo returns for more-accurate depth readings. The nearly-flush housing minimizes drag with only 5 mm (3/16″) extending outside of the hull.

Features:

• Engineered for center-console and trailered boats
• Low-profile protrusion below the hull
• No affect on your boats running performance
• Arrow on cap points toward keel when installed
• Built-in temperature sensor
• Boat Size: Up to 8 m (25′)
• Bronze transducer housing

Specifications:

• Weight: 1.4 kg (3 lb)
• Hull Deadrise: Up to 24°
• Acoustic Window: Urethane

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:

• Temperature: Yes
• Mounting Style: Thru-Hull
• Pins: 7
• Box Dimensions: 1″H x 5″W x 8″L WT: 4.9 lbs

Quick Guide (pdf)
Owner’s Manual (pdf)
Brochure (pdf)
