Raymarine E66085 B60-20 Tilted Transducer Compatible with DSM300/DSM250 Models

Description

B60 Tilted Element™ 20°
20° titled version is designed for 16° – 24° deadrise angles
For use with Raymarine DSM250/DSM300/DSM300G/DSM30/CP300
The bronze B60-20° provide a vertical beam without a fairing. Inside the housing, the ceramic element is tilted to provide built-in deadrise compensation. The resulting vertical beam provides excellent echo returns for more accurate depth readings. The nearly flush housing minimizes drag with only 5 mm (3/16″) extending outside of the hull.
Features:

• Depth/Temp
• 50/200 kHz
• 600w RMS
• Mid-performance
• Bronze

Specifications:

• Chirp: No
• Cable Length (Feet): 33′
• Temperature: Yes
• Speed Included: No
• Mounting Style: Thru-Hull
• Imaging: Standard
• Box Dimensions: 3″H x 7″W x 7″L WT: 5.85 lbs

Owner’s Manual (pdf)
Brochure (pdf)
